KORLOY-1-02-039116: CNMM643-VT NC5330 / CNMM190612-VT NC5330; 80 deg Diamond Insert, 10-Pack

 data-zoom=
 data-zoom=
  • Load image into Gallery viewer, KORLOY-1-02-039116: CNMM643-VT NC5330 / CNMM190612-VT NC5330; 80 deg Diamond Insert, 10-Pack
  • Load image into Gallery viewer, KORLOY-1-02-039116: CNMM643-VT NC5330 / CNMM190612-VT NC5330; 80 deg Diamond Insert, 10-Pack

KORL-1-02-039116

Brand: KORLOY

Ships From Mfr: Stocked in Korea

MSRP $254.30

Price: $193.27

Regular price
$193.27
Sale price
Regular price
Unit price
per

40711008059565


Korloy Part Number: 1-02-039116
Korloy's Turning Inserts are a great blend of value and quality. Respected as a top brand, Korloy is a go to for many machinists. Korloy produces thousands of inserts each month for shipment all of over the world. Be confident that Korloy will work for you.
Korloy's NC5330 grade is for machining stainless steel but can be used for general cutting of mild steel and forged steel. This grade provides excellent cutting performance in hard to cut materials which are vulnerable to built up edge, due to the high toughness substrate with improved fracture resistance and the coated layers. ISO P30-P35, M25-M35, K15-K25, S15-S25
The VT chip breaker is for heavy duty cutting. Designed specifically for heavy machining.

  • Sold in package of 10 pieces
  • Coating: CVD / TiCN+Al2O3+TiN
  • Tool Material: Carbide
  • Used For: Cast Iron | Stainless Steel | Steel | Exotic

***Product image may be different than actual product.


Brand: KORLOY
Type: Turning/ Boring Inserts
Insert Style: CNMM
Insert Shape: 80 deg Diamond
Insert ANSI: CNMM643-VT NC5330
Insert ISO: CNMM190612-VT NC5330
Insert Size: 643
Relief Angle: 0
Insert IC: 3/4 in.
Insert Radius: 0.047 in.
Insert Thickness: 1/4 in.
Chipbreaker: VT
Insert Grade: NC5330
Coating: CVD / TiCN+Al2O3+TiN
Tool Material: Carbide
Application Material Used For:: Cast Iron | Stainless Steel | Steel | Exotic
Prop 65: Yes
Country Of Origin: IMPORT
Weight: 0.059 lbs.
Ships From Mfr: Stocked in Korea
