Briney B311-09A-HTHS: High Torque Pull Stud (Retention Knob) For V-Flange Tooling, BT30 Taper, M12x1.75 Thread, 60° Angle

Briney B311-09A-HTHS: High Torque Pull Stud (Retention Knob) For V-Flange Tooling, BT30 Taper, M12x1.75 Thread, 60° Angle
Briney B311-09A-HTHS: High Torque Pull Stud (Retention Knob) For V-Flange Tooling, BT30 Taper, M12x1.75 Thread, 60° Angle

B311-09A-HTHS

Brand: BRINEY

Ships from Manufacturer; Usually Ships Same Day If Order Is Place Before 3pm cst

Price: $45.75

$45.75

39895251714221


Briney Tooling Systems Part Number: B311-09A-HTHS
Briney's Retention Knobs (Pull Studs) are made in the USA from the finest steels. Covered by a limited Lifetime Guarantee, these retention knobs will out preform all others. Please check your machine specifications carefully when ordering to ensure the proper fit and use.

  • USA Made
  • Precision Ground
  • Laser Marked
  • Limited Lifetime Guarantee

***Product image may be different than actual product.


Brand: BRINEY TOOLING SYSTEMS
Type: Retention Knobs-High Torque
Model: 311-09A
Knob Diameter (in): 0.431
Threads: M12x1.75
Neck Diameter (in): 0.274
Angle: 60
Thru-Coolant: No
O-Ring: No
Pilot Diameter (in): 0.491
Distance From Under Flange to Top Of Knob: 0.707
Country Of Origin: USA
Prop 65: Yes
